Ürün Detayları
Menşe yeri: ÇİN
Marka adı: Dingang
Sertifika: SGS,ITS,BV
Model numarası: Dingang - Ppal
Ödeme ve Nakliye Şartları
Min sipariş miktarı: 1000 kg / 1 metrik ton
Fiyat: pazarlık edilebilir
Ambalaj bilgileri: Ahşap paletli denize elverişli ambalaj
Teslim süresi: 30-45 gün içinde
Ödeme koşulları: L/C Sight veya% 30 T/T depozit olarak önceden ve b/l kopyasına karşı% 70 denge
Yetenek temini: Ayda 5000 ton /
İsim: |
Hazırlıklı alüminyum bobin |
Alaşım: |
5754 |
Kalınlık: |
1.2mm |
Genişlik: |
1220mm |
Alaşım ya da değil: |
Alaşım |
Başvuru: |
İnşaat endüstrisi |
Örnek: |
Mevcut |
Kaplama kalınlığı: |
PVDF: 25'ten az değil: 18umdan az değil |
Geri dönüştürülebilir: |
Evet |
İsim: |
Hazırlıklı alüminyum bobin |
Alaşım: |
5754 |
Kalınlık: |
1.2mm |
Genişlik: |
1220mm |
Alaşım ya da değil: |
Alaşım |
Başvuru: |
İnşaat endüstrisi |
Örnek: |
Mevcut |
Kaplama kalınlığı: |
PVDF: 25'ten az değil: 18umdan az değil |
Geri dönüştürülebilir: |
Evet |
Product Overview
Grade: AA5754 (5xxx series Al-Mg alloy, Mg content 2.6%-3.6%)
Temper: H111 (Strain-hardened & partially annealed, balanced formability and strength)
Thickness: 1.2mm (Standard for medium-strength structural applications)
Coating: PVDF/PE pre-painted finish (20-30μm thickness, custom colors available)
| Product | Color Coated Aluminum Sheet/Prepainted Aluminium Coil |
| Thickness | 0.1-1.6mm |
| Width | 30-1600mm |
| Material | 1050, 1060, 1100, 3003, 3004, 3105, 5052, 5005, 5754, 5083, 6061,8081 etc |
| Temper | O, H12, H14, H16, H18, H24, H26, H32, H34, etc |
| Inner Diameter | 405mm,505mm,150mm,etc. |
| Color | RAL, Pantone Color Or As Alient's Demand |
| Coating thickness | PVDF Paint Coating: Not Less Than 25um |
| PE Paint Coating : Not Less Than 18um | |
| Packing | Export Standard Wooden Pallets (Eye To Wall,Eye To Sky) |
| Payment Terms | L/C at sight or 30% T/T in advance as deposit, and 70% balance against the B/L copy. |
| MOQ | 3 Tons Per Specification |
| Delivery Time | Within 30-45 Days |
| Loading Port | Shanghai,Ningbo,Qingdao,Tianjin Port and Etc |
| Application | Aluminum Roofing,ACP,Roller Shutter Window,Roller Shutter Door,Aluminum Ceiling,Aluminum Grilling,Aluminum Downspout System,Home Appliance's Plate, body tank of cold chain truck,high speed rail,aluminum pull ring,food packaging,outer packing case of capacitor,external contour of letter channel |
1.Body Panels
Vehicle doors, hoods, trunk lids, fenders
Complex curved surfaces in luxury car designs
2.Structural Components
Chassis reinforcements, cross members, roof rails
EV battery enclosures and thermal management systems
3.Exterior Trim
High-exposure parts in coastal/high-humidity regions (e.g., side skirts, bumper brackets)
1.Superior Corrosion Resistance
2.Optimal Strength-Weight Ratio
3. Excellent Formability for Complex Shapes
4. Superior Surface Quality & Coating Adhesion
5.Weldability & Process Compatibility
6. Sustainability & Life-Cycle Benefits
